C-DRY Series, Centrifugal Dryer Machines

Working principle of our C-DRY series dryers; It is based on the principle of drying the products with centrifugal force and hot air. It has a solid construction and easy use thanks to its discharge system. In this series, the basket is fixed and cannot be removed.

YOU CAN CONTACT US FOR DETAILED INFORMATION.

Polling Form (#3)

PARTS OF THE CENTRIFUGAL DRYER

Details of the C-DRY Series Centrifugal Dryer

ADVANTAGES OF C-DRY SERIES CENTRIFUGAL DRYER MACHINE

Long service life with a basket made of 500 x 300 mm or 400 x 300 mm stainless steel perforated sheet.

Rotation speed of 500 rpm.

Resistance to acidic environments with double layer epoxy paint.

Extra drying facility with optional hot air blow unit.

Fast stop with motor brake.

Electrical panel complying with CE norms.

FOR DETAILED INFORMATION, YOU CAN CONTACT US ON WHATSAPP.

Sorry, no posts matched your criteria.

DVM Series Product Specifications

Description C-DRY 80
Inox basket dimensions (mm) 350×800
Capacity (kg) 80
RPM/min (optional inverter) 480
Heating power (kW) 4,8
Fan power (kW) 0,37
Fan speed (RPM) 3000
Brake motor power (kW) 1,10
Electric power supply (three phase) 380
Machine weight (kg) 350
Cover opening 6 bar, pneumatic
Door opening 6 bar, pneumatic
Body tilting gearbox (RPM/min) 3
